Basic Info.
Model NO.
QPL-Car-08
Location
Private Use
Installation
Wall Mounted
Charge Method
Normal Charge
Package Gross Weight
300.000kg
Transport Package
Cartons
Specification
210.00cm * 60.00cm * 50.00cm
Trademark
QPL
Origin
Chain
HS Code
8504409999
Production Capacity
50000000 Pieces/Year
Product Description
7kw
22kw
3.5kw
various charger type
| Item | Technical Specification (Table 1) | Technical Specification (Table 2) |
|---|---|---|
| Rated Power | 7KW (1 Phase) / 11KW (3 Phase) / 22KW (3 Phase) | 14KW (1 Phase) / 22KW (3 Phase) / 44KW (3 Phase) |
| Optional Features | WIFI / 4G / OCPP1.6 / LAN | WIFI / 4G / OCPP1.6 / LAN |
| Charging Interface Types | GB/T20234 / IEC61851 / SAEJ1772 / NACS | GB/T20234 / IEC 61851 / SAE J1772 / NACS |
| Input and Output Voltage | AC220V+10% (1 Phase) / AC380V+10% (3 Phase) | AC220V+10% (1 Phase) / AC380V+10% (3 Phase) |
| Output Current | 16A / 32A / 50A | 16A / 32A / 50A |
| Frequency | 45-65Hz | 45-65Hz |
| Technical Specification | Details (Table 1) | Details (Table 2) | Details (Table 3) |
|---|---|---|---|
| Total Power | 20kW/30kW/40kW/60kW | 60kW/80kW/120kW/160kW | 160kW/180kW/210kW/240kW |
| Device Model | WDHY-1000V-20KW~60kW | WDHY-1000V-60kW~160kW | WDHY-1000V-160kW/180kW/210kW/240kW |
| Execution Standard | GB/EU/JP/US Standards | GB/EU/JP/US GBT/CCS1/CHAdeMO/CCS2 | GB/EU/JP/US GBT/CCS1/CHAdeMO/CCS2 |
| Maximum Power per Gun | 60kW | 60kW | 80kW |
| Emergency Stop Button | Yes | Yes | Yes |
| Communication Protocol | OCPP U.25 or Compatible | OCPP 1.6J or Others | OCPP 1.6J or Others |
| AC Input Voltage | 380V (-25%, +25%) AC | 380V (-25%, +25%) AC | 380V (-25%, +25%) AC |
| AC Input Frequency | 50Hz ± 10% | 50Hz ± 10% | 50Hz ± 10% |
| Output Voltage Range | 50V~1000VDC | 50V~1000VDC | 50V ~ 1000VDC |
| IP Protection Level | IP54 | IP54 | IP54 |
| Output Mode | Power Distribution | Single/Dual Gun Average Power Distribution | Single/Dual Gun Average Power Distribution |
| Power Factor | cosφ=0.99 | ≥ 0.99 | ≥ 0.99 |
| Efficiency Rating | Class A | - | - |
| Static Overall Efficiency | 94% | 94% | 94% |
| Auxiliary Power Supply | - | 12V | 12V |
| Relative Humidity | ≤95% | ≤ 95% | ≤ 95% |
| Soft Start Time | 3-8S | 3-8S | 3-8S |
| Load Voltage Drop | ±0.5% | - | - |
| Output Voltage Error | ±0.5% | ≤ ± 0.5% | ≤ ± 0.5% |
| Current Regulation Accuracy | ±1%, ±10% | ≤ 1% | ≤ 1% |
| Output Voltage Ripple | ±1% | ≤ 1% | ≤ 1% |
| Current Sharing Imbalance | ±5% | ≤ 5% | ≤ 5% |
| Load Adjustment Rate | ±1% | - | - |
| Power Quality Requirement | GBT 19262-2014.5.4 | GB/T 19826-2014: 5.4 | GB/T 19826-2014: 5.4 |
| Operating Mode | Card Scan/Small Window Scan | Card Scan/Small Program Scan Code | Card Scan/Small Program Scan Code |
| Stability of Current Regulation | ±5% | - | - |
| Input Voltage | AC220V/380V | - | - |
| Display Method | 7-inch Touch Screen | 7-inch Touch Display Screen | 7-inch Touch Display Screen |
| Installation Method | Floor Standing, wall mounted | Floor Standing,wall mounted | Floor Standing,wall mounted |
| Operating Temperature | -35ºC~+55ºC | - | -35°C ~ +55°C |
| Charging Battery Type | 5V/7mA | - | - |
| Harmonic Distortion Rate | ≤5% | - | ≤ 5% |
| Charging Gun Length | - | - | 5m/7m/8m |
Q1What service can you supply?
We have our brands products and OEM/ODM service.
Q2:Can I test the sample?
A:Yes, we can provide samples for testing for a fee.
The cost of the sample will be refunded when the next batch of customer mass production orders,
but shipping costs are not included.
Q3:How do you ensure quality?
A:The company designs and develops the system and circuit board according to the requirements of customers for CE,
using high quality materials to ensure the good performance of the system,
and carries out quality control tests for many times before delivery,
so that the products can meet the requirements of automobile dealers and are durable.
Q4:Are you a trading company or a manufacturing company?
A:We are the manufacturers.
Q5:Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
How long do you offer the warranty?
A:1 year
