Basic Info.
Model NO.
BC-22kW-RFID
Installation
Wall Mounted
Charge Method
Normal Charge
Product Name
EV Charging Station
Plug Type
Type 2 / IEC 62196-2
Power
22kw
Rated Current
32A 3phase
Function
Screen Display
Color
Black or Customization
Cable Length
20FT
Car Fitment
Adapted All Models
Dimension(W/H/D)
295/195/65mm
IP Rating
IP66
Application
Home Use/ Commercial Use
Weight
8.5kg
Working Temperature
-25ºC~+55ºC
OEM Service
Yes
Warranty
12 Months
Transport Package
1 Carton Box
Specification
IEC 62196-2
Trademark
BESEN
Origin
China
Product Description
| Electrical Specification | |
| Input Voltage/Output voltage | 100V /230V /400V (Three Phase) |
| Input frequency | 47~63Hz |
| Max. output power | 7.6KW (Single Phase)/22KW (Three Phase) |
| Max. output current | 32A |
| Charging interface type | IEC 62196-2, SAE J1772 |
| Function and Accessory | |
| Ethernet/WIFI/4G | No |
| LCD | 3.5-inch color display |
| RCD | Type A / Type A+ 6mA DC |
| LED Indicator light | Yes |
| Intelligent power adjustment | Yes |
| RFID | Opt |
| APP | Opt |
| Working Environment | |
| Protection degree | IP 66 |
| Environment temperature | -40ºC ~ +75ºC |
| Relative humidity | 0-95% non-condensing |
| Maximum altitude | <2000m |
| Cooling | Natural air cooling |
| Standby power consumption | <8W |
| Certificate | |
| CE | FCC |
| ROHS | CCC |
| CSA | IK 10 |
| IP 66 | |
