Basic Info.
Installation
Floor Type
Charge Method
Quick Charge
Operation Temperature
-40°c~+60°c
Protection Level
IP55
Gun Cable Length
Car:4.5m Bus:6m
Transport Package
Wooden Box with Pallets
Specification
800*500*1700mm
Trademark
Copartner
Origin
China
HS Code
8504409999
Production Capacity
10000 Piece/Pieces Per Month
Product Description
Gold Manufacturer Fast EV Charger 20Kw 30Kw Electric Car Charging Station For Home
| Parameters | Requirements | |
| General Requirements | ||
| EV Charger Type | DC | |
| Charger Capacity | 20KW | 30KW |
| Product Model NO. | ENC-DCB020A ANSI-DCB020A JIS-DCB020A | ENC-DCB030A ANSI-DCB030A JIS-DCB030A |
| Mounting | Wall-Mounted | |
| Input Requirements | ||
| AC Supply System | Three-Phase, 5 Wire AC system | |
| Nominal Input Voltage | AC380V±15% | |
| Input Frequency | 45-65Hz | |
| Environmental Requirements | ||
| Ambient Temperature Range | -25 to 55°C | |
| Ambient Humidity | 5 to 95% | |
| Storage Temperature | -40 to 70°C | |
| Mechanical Requirements | ||
| IP Ratings | IP 54 | |
| Cooling | Air-cooled | |
| Output Requirements | ||
| Number of Outputs | 1 | |
| Type of Each Output | DC200-750V DC150-500V(JIS) | |
| Single Output Max. Current | 80 Amp | 125 Amp |
| Power Factor | ≥0.99(50% load above) | |
| User Interface & Display Requirements | ||
| Display & Touch-Screen Size | 4.3 Inches Touch Screen with Shell | |
| User Authentication | QR Code/RFID Card /Password Login | |
| Metering Information | Consumption Units | |
| Communication Requirements | ||
| Communication between EVSE and Central server | OCPP 1.6J Protocol (Optional) | |
| Interface between Charger and CMS | Ethernet/3G/4G/WIFI (Optional) | |
| Protection & Safety Requirements | ||
| Executive Standard | IEC 62196 2017, IEC 61851 2017, SAE J1772,CHAdeMO etc. | |
| Safety Parameters | Over Current, Over Voltage, Under Voltage, Residual Current, Surge Protection,Leakage Protection, Short Circuit, Over Temperature, etc. | |
