Basic Info.
Number of Charging Interfaces
One Pile with One Charge
Location
Private Use
Installation
Floor Type
Charge Method
Normal Charge
Quality
High Quality
Customized
Available
Package
Cartons
After-Sales Service
Forever
Type
Fast EV Charging Station
Certification
CE
Warranty
12 Months
Transport Package
Cartons
Specification
cast iron
Trademark
welldone
Origin
China
HS Code
84131100
Production Capacity
500pieces/Month
Product Description
Key Features of the Smart Charging Station
- Intelligent Monitoring: The smart controller measures, controls, and protects the charging station, monitoring its operating status, fault conditions, and managing the charging process.
- Smart Metering: An AC intelligent electricity meter is equipped for AC charging metering, providing robust communication capabilities and uploading information to the charging controller and network operation platform via RS485.
- Easy Charging: Scan a QR code using the charging station's mobile app to start charging.
- Comprehensive Protection: Includes input/output overvoltage and undervoltage protection, short-circuit protection, overcurrent protection, leakage protection, grounding detection, and overtemperature protection.
- High Compatibility: Compatible with all national standard vehicle models available in the market.
- Adjustable Power: Charging power can be adjusted to meet the requirements of different vehicles in different locations.
- IP Rating: IP54 (terminal).
| Item | Technical Specification (Table 1) | Technical Specification (Table 2) |
|---|---|---|
| Rated Power | 7KW (1 Phase) / 11KW (3 Phase) / 22KW (3 Phase) | 14KW (1 Phase) / 22KW (3 Phase) / 44KW (3 Phase) |
| Optional Features | WIFI / 4G / OCPP1.6 / LAN | WIFI / 4G / OCPP1.6 / LAN |
| Charging Interface Types | GB/T20234 / IEC61851 / SAEJ1772 / NACS | GB/T20234 / IEC 61851 / SAE J1772 / NACS |
| Input and Output Voltage | AC220V+10% (1 Phase) / AC380V+10% (3 Phase) | AC220V+10% (1 Phase) / AC380V+10% (3 Phase) |
| Output Current | 16A / 32A / 50A | 16A / 32A / 50A |
| Frequency | 45-65Hz | 45-65Hz |
