Basic Info.
Product Description
| MODEL | ZHEV-DC30-Y | ZHEV-DC40-Y | ZHEV-DC60-Y | ZHEV-DC80-Y |
| AC Input | ||||
| Input Voltage | 285VAC - 475VAC | |||
| Input Voltage | Three phases | |||
| AC Input Connection | 3P+N+PE | |||
| Max. Input Current | 57A | 76A | 115A | 152A |
| Frequency | 50Hz~60Hz | |||
| Power factor | ≥0.99 | |||
| DC Output | ||||
| Output Power Range | 30KW | 40KW | 60KW | 80KW |
| Output Voltage Range | 200V-750V | |||
| Output Current | 0-100A | 0-134A | 0-200A | 0-268A |
| Voltage Accuracy | ≤±0.5% | |||
| Current Accuracy | ≥30A±1%; | |||
| Efficiency | ≥93% | |||
| User Interface & Control | ||||
| Display | 7 inch touch screen | |||
| Support Language | English | |||
| Push Buttons | Emergency Stop | |||
| User Authentication | RFID System ISO/ICE 14443A/B | |||
| Display Information | Charging process and status / Alarm and warning message | |||
| Communication | ||||
| External | Ethernet,3G/4G, WIFI | |||
| Internal | CAN bus/ RS485 | |||
| Environmental | ||||
| Operating Temperature | -40~85ºC;25ºC(type); | |||
| Humidity | 20~95RH%;25RH%(type) | |||
| Altitude | ≤6000 feet(2000m) | |||
| IP level | IP54 | |||
| Cooling Method | Forced air | |||
| Mechanical | ||||
| Net Weight | 160kg | 160kg | 180kg | 180kg |
| Cable Length | 5meter | |||
| Dimension(W*D*H) | 550*650*1850mm | 550*650*1850mm | 550*650*1850mm | 550*650*1850mm |
| Warranty | 2 years | |||
Q: Are you the factory or trading company?
A: We are factory with more than 20 years in the field of DC power supply solution, traction power supply and new energies. We warmly welcome you for the visit.
Q: How is the delivery time?
A: Generally, the delivery time between 7-30 days after getting client's payment.
For accurate info depends on the products and the quantity, we can make further communication on this.
Q: Do you have MOQ requirements?
A: MOQ is 1 set for most of the products, only MOQ for 7KW, 11KW, 22KW ev charger is 10 sets.
A: How long is your warranty time?
Q: We provide 2 years warranty for our clients.
Q: Can you provide customized service?
A: Yes. we have been getting involved with the OEM and ODM projects since 2004.
So that we can provide professional customized service for our clients.
Q: Do you have after sales service?
A: Yes, we have the after-sales service team.
Our after-sales engineer Can give the support and instruction by video or phone call while needed.
Q: Do you make the test after finishing production?
A: Yes, our production engineer team will do the test while goods finished, and we will prvoide the test info to clients for reference before delivery.
